Challenge
Granting users complete control over their key stores for each individual business application necessitates providing each one with its own Hardware Security Module (HSM). This approach can be expensive and logistically complex. Users typically lack the resources and discipline required to effectively manage an HSM and ensure its security remains current.
Solution
Decanus facilitates seamless and affordable HSM management without compromising security. Its Remote-Control Terminal empowers you to oversee and independently manage up to 64 Primus HSMs across global locations effortlessly. Alternatively, it can handle one to 64 partition(s) on the Primus HSM autonomously, eliminating the necessity to activate or rely on HSM administration.
Key Benefits
Tamper-Proof User Interface
The Decanus Terminal features a securely extended user interface within a tamper-proof device, ensuring robust security for all operations.
Comprehensive HSM Functionality
Supports the full range of HSM functionalities, except for initial pairing, providing flexibility and ease of use.
Unique Design and Usage
The Decanus Terminal stands out with its distinctive approach to HSM management, offering unparalleled security and efficiency.
Technical Specifications
- PoE: Class 4, 51V DC
- Wall adaptor: 100 - 240V AC 60/50Hz, 12V DC
- DC PWR Input: 12V DC (9-14V DC)
- Standby: <0.5W
- On: max. 12W, typ. 4W
- WVGA: 800x480, 5"
- Brightness: 800 cd/m2
- Touch: PCAP
- Multicolor LED: RGB
- USB Host: Typ A, USB 2.0 HS
- USB Device: Typ B, USB 2.0 HS
- Ethernet: 100Base-TX
- Touchscreen
- On/off Button
- Console: FTDI, Virtual COM port
- Operation: 0 ... +40°C non condensing
- Storage: -20 ... +70°C non condensing
- Case: metal, with anti-tamper mechanisms
- Tamper battery: Lithium Thionyl Chloride 0.65g Li, IEC 60086-4 ,UL 1642, 3.6V
- 222 x 130 x 95mm (w x d x h)
